Automatic Sliding Sensor Glass Door/Auto Sensor Sliding Door Opener( transmission rail and cover is included)

Best Glass High Rating Product provide sliding door opener, door opener, sensor sliding door Wonderful New Automatic Sliding Sensor Glass Door/Auto Sensor Sliding Door Opener( transmission rail and cover is included). Get 37% discount Now! Now US $395.00/piece. Dont waste your time. Buy Now only in Trusted Seller Store!

One Complete Set Include the Parts As below Control panel x1 Receiver x 1 Motor gear box assembly x1 Return Pulley x1 Microwave sensor x2 Terminal input assembly x1 Tooth Belt 1*7m Power switchx 1 End stop x 3 Hanger roller bracketx 4 Remote control x2 Belt bracket link assembly x2 Device for yaw checkingx 1 Transmission rail and cover x 1.8meters

Notice:

1.The products we deliver include 1.8 meters transmission rail and cover,as usual, it is used for single leaf sliding door. if need longer, please kindly tell us the door width per leaf,Single or double leaf door.

Then we can count the price for you.Products on video is operation after install aluminum rail and cover, it is for your reference.

2. If the door is frameless, the optional accessory glass hunger is needed, the price will be a little higher, single leaf door need 2 pieces glass hunger, double leaves door need 4 pieces.

please contact us to adjust the price for you if need them.

3.Optional accessories such as safety beam, backup battery, magnetic lock, five key switch, access keypad, push button can be provided.

If order them and ship along with the automatic sliding door opener, it can save much shipping cost for you.

Automatic Sliding Sensor Glass Door Technical Data

Microwave Sensor

Infrared thermal, intelligent detecting.

24.125GHZ microwave sensor module imports from Europe, using the impact detection control ,intelligent optimization appliances.

It is highly independent of temperature and humidity and other environmental factors.

Accurate region sensor adjustment and extremely reliable performance make it run faster and more stable. The firing frequency of it is up to 24.125GHZ.

The accurate and sensitive induction and immunity to interference makes the whole perfect.

Type Of Motor

Microcomputer controller Efficient circuit, overload protection

Automatic doors controller is receiving signals from other sensors or detection switch for driving motor control door operating according to suitable manner.

The controller comes with its own 24V power supply switch, without using of transformers. Safety beam, access control, external electric locks, back up battery, two-door interlock port enabling customers to use it according to actual needs.

External remote control
The receiver can be plugged directly to the transmitter comes standard with two, if more transmitters, please contact customer service. Tips: Olide uses extrapolation receiver module, because the signal is better than a lot of built-in remote control(automatic code).
	Working Principle The remote control supports Olide brand automatic doors use, it should be inserted with the use of automatic doors controller. It is an adjustable automatic door (automatic, normally open, normally closed, semi-open) state. Normally close: The door has been turned off, the sensor is invalid. Normally open: the door has been in open state. Automatic: You can go into the normal induction. Semi-open: open the door half shut down automatically.

Glass Hanger And Floor Guider Accessories

Frame door connect parts	Floor guider accessories
If your door is framed and no need glass hanger , then we willsend four small iron parts fixed to the wood doors or other types of framed doors, keep your doors easily connected with our hunger roller bracket. As shown below:	If your door is framed and no need glass hanger, then we will send you floor guider for framed doors. If your door is frameless and need glass hanger, then we will send you floorguider for frameless doors. As shown below:
	Framed door floor guider Used on wooden doors, iron doors, or framed glass doors, so guide the door’s moving in correct direction.
	Frameless door floor guider Used on the framless glass door, so guide the door’s moving in correct direction.

Door Size

It is generally divided into single leaf door open and double open, double leaves door open is two leaves door fixed and two sliding. It is 3-5cm overlap portion between fixed door and sliding door,as shown below:

Sliding Glass Width: doorway width divided by 4. Fixed glass width: total width openings divided by 4 then plus 5cm (overlapping portion between the door). The net opening width up to 200cm, if wider, you can purchase the track lengthened.

Note: Door Weight: single leaf door open, the largest 160KG; double leaves door open: 125KG * 2

NOTE: If you need 3m track for double leaves glass doors, you can put two 2m tracks cut into1.5m to install.

Since the two glass doors movement separately, they work normally .It doesn’t matter the track formation is not related.

Standard Accessories

Standard accessories include End stopper, Last round, Off prevention device, Power switch,Connecting frame, belt , etc.

Fault Description

No reaction Door

No power	Check the power linecheck switch
Track with foreign body	Turn off the power, Push the door by hand, Determine whether the door is smooth movement
Door automatic protection	To confirm whether the external obstacles, Obstacle to run
Lock undischarged	Check whether there are external mechanical lock to lock the door
Unable to fully open the door	Semi-open mode	Check whether the remote control is set to semi-open mode
The door cannot be closed or abnormal operation	Sensor malfunction	check around the sensor in presence of continuous exercise equipment
	Control signal wire short circuit	It can return to normal after disconnecting the signal
	Microwave interference source exists around the door	Check the microwave interference sources
	Eye on the radio continued operation	Confirm whether the electric eye is covered with dirt
		Confirm that electric eye deviating from the correlation angles
The door is not running smoothly	Great running resistance	check whether there is any foreign body on guide rail
		check whether there is any obstacle on the door
	Open closed speed adjustment is not reasonable	confirm the speed control

Automatic Sliding Sensor Glass Door Profile Drawing

Automatic Sliding Sensor Glass Door Project From Clients

Optional Accessories

Packaging&Shipping

CE Certificate
