2 touch points 60 Inch IR Touch Screen Panels USB IR touch frame without glass

Best Glass High Rating Product provide touch frame, frame calligraphy, frame usb 2018 Limited 2 touch points 60 Inch IR Touch Screen Panels USB IR touch frame without glass. Get 14% discount Now! Now US $141.90/piece. Hurry buy Now before back to normal price! Normal price US $165.00. Dont waste your time. Buy Now only in Xintai Touch Store Trusted Seller Store!

2 touch points 60 Inch IR Touch Screen Panels USB IR touch frame without glass Infrared Touch Panel Working Principal IR Touch Screen is a touch frame which is usually installed in front ofthe display screen. The frame is integrated with printed circuit board which contains a line of IR-LEDs and photo transistors hidden behind the bezel of thetouch frame. Each of IR-LEDs and photo transistors is set on the opposite sides to create a grid of invisible infrared light. The bezel shields the parts fromthe operation Super advantages for 60 inch 2 points IR multi touch screen : 2 points touch (Multi touch) Support zoom in/out, display rotation USB interface, Drive free, plug and play Supporting 2 points touch under windows7, windows8 and Android system Supporting single touch under Linux System Withstands severe environments Stable, no-drift calibration performance Vandaproof and abrasion-resistant screens, ideal for rugged applications Parallax-free performance for LCD displays Sealable against contaminants Operable in various light conditions, indoor and outdoor Infrared Dual/Multi Touch Basic Characteristics: 2 points touch (Multi touch) Support zoom in/out, display rotation Withstands severe environments Stable, no-drift calibration performance Vandaproof and abrasion-resistant screens, ideal for rugged applications Parallax-free performance for LCD displays Sealable against contaminants Operable in various light conditions, indoor and outdoor Size General Size 15 inch to 159 inch
Fit in with	Panel display device
Performance
Touch Mode	Single-point touch, Multi-touch, drag, draw-line, rotate, zoom in/out
Resolution(Interpolation)	4096*4096
Linearity Error	<1.5mm
Response Speed	<15ms
Mechanical
Input Method	Finger or gloved hand (rubber ,cloth or leather)
Minimum Touch Object	2.5 mm X 2.5 mm
Vandal-proof	No break by 1-pound steel ball dropping from 130 cm high
Optical
Glass:	Without glass, 4mm glare, AG (anti-glare), or AR (anti-reflective) glass optional
Light Transmission	92%
Gloss	Antiglare surface (curved or flat): 95 ± 15 gloss units or 65 ± 15 gloss units
Environmental
Temperature	Operating Range: -20°C ~ 70°C;
	Storage Range: -40°C ~ 85°C
Relative Humidity	Operating Range: 0%~90% RH (no dew falls)
	Storage Range: 0% to 95% RH (no dew falls)
Ambient Light	Direct sunlight 90°to ±30° to the display surface Touch detection operational
	Direct sunlight all angles to display surface Free of false touch reports
Electrical
Operation Voltage	Typical +DC 5V, +4.75V to +5.25V
Power Supply	Size under 52”(include 52”)USB or PS/2 Interface, power ripple max.200mV rms
	Size above 52”(52” not included): external AC-DC power adaptor
Interface	Full Duplex USB 2.0 (Full Speed) Plug and play compatible
	Plug and play compatible
Current	Typical 150MA@+5VDC; 350mA, maximum
Power	<1.5W, operating current<300mA
Electrostatic Protection	15 kV air / 8 kV contact discharges (EN61000-4-2,1995 :Level 4)
Controller	Integration inside touch panel
Agency Approvals	CE, FCC, Rohs
Operating System
Operation System :windows 7, windows8, Android, Linux
